ECS Elitegroup H61H2-M6 (V1.0) [10/72] Introducing the motherboard
![ECS Elitegroup H61H2-M6 (V1.0) [10/72] Introducing the motherboard](/views2/1212510/page10/bga.png)
6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SYS_FAN 3-pin system cooling fan connector
6. SPI_DEBUG SPI debug header-for factory use only
7. SATA1~4 Serial ATA 3.0 Gb/s connectors
8. SPDIFO SPDIF out header
9. F_PANEL Front panel switch/LED header
10. SPK Speaker header
11. CASE CASE open header
12. ME_UNLOCK ME unlock header-for factory use only
13. F_USB1 Front panel USB 2.0 header (it supports EZ Charger)
14. F_USB2 Front panel USB 2.0 header
15. CLR_CMOS Clear CMOS jumper
16. COM Onboard serial port header
17. FDD Floppy disk drive connetor
18. F_AUDIO Front panel audio header
19. PCI1~2 32-bit add-on card slots
20. PCIEX1 PCI Express x1 slot
21. PCIEX16 PCI Express slot for graphics interface
22. ATX12V 4-pin +12V power connector
1. CPU Socket
LGA1155 socket for new 2nd & 3rd Generation Intel
®
Core
TM
Family/ Pentium
®
/Celeron
®
Processors
