ECS Elitegroup H61H2-M6 (V1.0) [55/72] Using bios
![ECS Elitegroup H61H2-M6 (V1.0) [55/72] Using bios](/views2/1212510/page55/bg37.png)
51
Using BIOS
fCPU OverClocking Configuration
Scroll to this item to view the following screen:
Enhanced Intel SpeedStep
Technology
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 30
Enhanced Intel SpeedStep Technology [Enabled]
Intel Graphics Configuration
Graphics Core Ratio Limit 22
Graphics Voltage(1/256) 0
CPU Ratio (30)
This item allows users to control non turbo CPU ratio.
CPU Frequency (100)
This item shows the information of the CPU frequency.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep
Technology).
Graphics Voltage(1/256) (0)
This item allows you to adjust the internal GFX voltage.
Graphics Core Ratio Limit (22)
This item allows you to control the internal GFX Turbo ratio
.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Exit
