50
Using BIOS
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
M.I.B III (MB Intelligent BIOS III)
Memory Voltage Control
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology [Enabled]
Auto Detect DIMM/PCI Clk [Enabled]
Spread Spectrum [Enabled]
Intel(R) Pentium (R) CPU G860 @ 3.00GHz
Processor Speed 3000 MHz
Memory Frequency 1333 MHz
Total Memory 2048 MB (DDR3 )
Memory Voltage Control
f
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
f
f
f Memory Voltage Control
Scroll to this item to view the following screen:
Auto: DDR3 standard voltage
Low Voltage: Lowest voltage
Supported by memory modules
Manual: User customized
Memory Voltage Control
Memory Voltage Config [Auto]
Memory Voltage Config (Auto)
This item allows users to select memory voltage config.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Press <Esc> to return to the M.I.B III menu page.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset
M.I.B III Boot Security Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Exit
