Chapter 1
2
H77H2-M USER MANUAL
CPU
Specifications
• Intel
®
H77 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen3 slot
(The PCI Express x16 slot conforms to PCI Express 3.0 Standard)
• 1 x PCI Express x1 Gen2 slot
• 2 x PCI slots
• Supported by Intel
®
H77 Express Chipset
- 4 x Serial ATA 3Gb/s devices
- 2 x Serial ATA 6Gb/s devices
- RAID 0, RAID 1, RAID 5, RAID 10 configuration
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-Sub port (VGA)
• 1 x DVI port
• 1 x HDMI port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 3.0 ports compatible to both USB 3.0/2.0 devices (blue)
• 1 x Audio port (1x Line in, 4x Line out, 1x Optical SPDIF Out)
Rear Panel I/O
LAN • Realtek 8111E Gigabit Lan
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• ITE IT8893
- Supports 2 PCI slot expansion
Extra Chips
• LGA1155 socket for new 3rd Generation Intel
®
Core
TM
Family/
Pentium/Celeron Processors
• Supports New 22nm Intel
®
Core
TM
micro-architecture
• Supports Intel
®
Smart Response Technology
• DMI 5.0GT/s
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 3 x USB 2.0 headers support additional six USB 2.0 ports
(F_USB1 supports EZ charger)
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 2 x Serial SATA 6Gb/s connectors
• 1 x COM header
Internal I/O
Connectors &
Headers
• Realtek ALC892
-
8 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
