H77H2-M USER MANUAL

Chapter 1

• AMI BIOS with 64Mb SPI Flash ROM

- Supports ECS MIB III Utility

a. CPU Voltage Adjustable

b. Memory Voltage Adjustable

c. IMC Voltage Adjustable

d. Graphic Voltage Adjustable

- Supports Plug and Play, STR(S3)/STD(S4), Multi Boot

- Supports Hardware Monitor

- Supports ACPI 3.0 version & DMI

- Supports Audio, LAN, can be disabled in BIOS

- Supports ECS GUI UEFI BIOS

- Supports Integrated Graphic Over-Clocking

- Supports Dual-Monitor function

- F7 hot key for boot up devices option

- Supports Pgup clear CMOS Hotkey (Has PS2 KB Model only)

System BIOS

Form Factor

• Micro-ATX Size, 244mm x 220mm

• 1 x Case open header

• 1 x SPDIF out header

• 1 x Front Panel audio header

• 1 x Front Panel switch/LED header

• 1 x Speaker header

• 1 x TPM header

• 1 x ME_UNLOCK header

• 1 x Parallel port header(LPT)

• 1 x CLR_CMOS header

• Supports eBLU

• Supports eDLU

• Supports eSF (Warning: Microsoft .NET Framework 3.5 is

required)

AP Suppport
