3. Specifications

The manufacturer reserves himself the right to make the manual's content or

function change without any preliminary notification of the users.

power generator

4. Putting the Power Generator into Operation

Operating conditions

Power stations provide steady work at ambient temperature from -15°C to +40°C, (gasoline and oil

type should be picked up according to these conditions). Relative humidity <60%.

Generating set performance is reduced by approximately 4% for every additional 10°C and/or

approximately 1% for every additional 100m in altitude.

Specifications\Model WHS 190 DC WHS 210 DC

Rated voltage, V 230 230

Rated frequency, Hz 50 50

Max. output, kWA 4,5 5

Rated output, kW 4 4,5

Rated current, А 18,2 20,5

Cos phi

Motor type

Power, kW/hp

Fuel

Tank capacity, l 25 25

Oil tank capacity, l 1,1 1,1

Oil type

Starting system

Weight (without fuel), kg 89 92

Dimension, mm 729x537x592 729x537x592

Welding current type

Welding current, А 50-190 60-210

Rated no-load voltage, V 65 65

Welding current of duty cycle 60%, A 120 140

Мin. electrode diameter, mm

Маx. electrode diameter, mm 4 5

HONDA GX390

automotive unleaded gasoline

9,6/13

Welding specifications

IP23

1,6

SAE 10W30

electric/recoil starter
