3. KNOW YOUR PRODUCT
KNOW YOUR PRODUCT
1. Handle
2. ON/OFF switch
3. Upper section
4. Filter basket
5. Float switch
6. Clamps
7. Tank
8. Hose connection
9. 2 castors
10. Hose set
11. Plastic tube
11a. Metal telescopic tube
12. Blow connection
13. Floor nozzle
13a. Combo nozzle
WARNING!
In the specification are all possible adaptation which may be included product.
Real grade products described in the "ACCESSORIES".
UNPACKING
Due to modern mass production techniques, it is unlikely that your electric appliance
is faulty or that a part is missing. If you find anything wrong, do not operate the
appliance until the parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.
Carefully unpack the contents of the box.
1. Hold the two clamps (6) fastening the upper section (3) in its position and fold
them upwards (Fig.1).
2. Loosen the clamps, remove the upper section (Fig.2) and take out the contents
from the tank.
Please check the parts using the list shown above to make sure they are complete
and that there has been no damage in transport.
ASSEMBLY
• Hold the two clamps fastening the upper section in its position and fold them
upwards (Fig.1).
• Loosen the clamps and lift the upper section outwars(Fig.2).
• Turn the tank upside down on a stable leveled clean surface.
• Fasten the pedestals (16) of the castors (9) to the tank with screws. (Fig. 3)
• Insert the castors (9) into their pedestals (16) by pressing. (Fig. 4)
• Fasten the assembled to their pedestals big rear wheels (20) to the tank with
screws. The wheels are marked (with L and R) for mounting to the left (L) and to
the right (R).
• Place the tank back in normal position.
• Insert a filter appropriate for the work to be done.
• Place the upper section back on the tank.
14. Dust bag
15. Crevice nozzle
16. Castor pedestals
17. Clasp seat
18. Accessory holder
19. Foam filter
20. 2 big wheels
21. PET cartridge filter
22. Dry filter
23. Cable hook - upper
24. Cable hook - lower
25. Drain outlet
26. Air control handle
27. Buit-in socket
8
4. OPERATION INSTRUCTIONS
• Align the upper section with the clamps.
• Attach the clamps to the upper section and press them downwards until an audible
"click" is heard.
• Insert the larger end of the hose (10) into the tank front inlet (8) (Fig.5). The hose
connector tooth shall align with the groove in the tank front inlet. Rotate the hose
connector in the direction marked with an arrow.
• Select an appropriate nozzle and/or hose and attach them to the hose (10) (Fig.6).
• After you have completed vacuuming and cleaning the appliance, store the acces-
sories in the corresponding holders (18) (Fig.7).
OPERATION INSTRUCTIONS
These electric appliances are supplied from single-phase alternating current mains
only. The vacuum cleaners must be connected to grounded sockets. These electric
appliances are radio suppressed in compliance with EMC Directive 2004/108/EC.
These electric appliances are designed to vacuum the dust generated during
operating power tools. For this purpose they are equipped with a built-in socket (27),
for inserting the cable plug of the power tool. The vacuum cleaner will switch on
automatically as soon as you switch on the power tool.
When you switch off the power tool, the vacuum cleaner will also switch off after a
preset delay.
Prior to initial operation
• Make sure power supply voltage corresponds to the value indicated on the name
plate with technical data of the appliance.
• Make sure the cable and the plug are in order. If the replacement of the supply
cable is necessary, this has to be done by the manufacturer or his agent in order
to avoid a safety hazard.
• It is absolutely necessary for you to read, understand, and observe the section
entitled "Safety instructions for vacuum cleaners".
Dry vacuum cleaning
WARNING! Never vacuum up hazardous materials.
WARNING: Wet cleaning with mounted filter elements for dry cleaning is
absolutely forbidden.
If an incorrect dust bag is used, then the guarantee becomes void.
The following filter elements are used for dry cleaning:
а) The dry filter (22) and the dust bag (14) can be used separately or together.
When they are used together the filtering effectiveness is increased.
b) The cartridge filter (21) and the dust bag (14) can be used separately or together.
When they are used separately the cartridge filter efficiency is much higher than
the dust bag efficiency.
Filter efficiency: Cartridge filter - high, Dry filter - medium, Dust bag - low
• Make sure that the appliance is not plugged into the power supply.
• Ensure that the tank (7) is clean and dry.
Dry filter
Place the dry filter (22) onto the filter basket (4). (Fig. 8)
Cartridge filter
Place the cartridge filter onto the filter basket (4) (Fig.9) and screw the locking cap
to close the filter basket. After prolonged use the cartridge filter must be cleaned by
tapping and brushing it.
