11
WARNING! Use only original STATUS accessories. The use of non original spare
parts or accessories presents potential danger and voids the guarantee.
MAINTENANCE
• Make sure that the appliance is not plugged into the power mains.
• Take out the suction hose (10) from the tank.
• Release the clamps (Fig.1) and remove the upper section from the tank (Fig.2).
• Clean up any dirt or debris from the tank and hose.
• Clean the foam filter (19) by washing it with a mild detergent.
• Check the hose and connections and inspect the power cord for any damage.
• When the foam foam filter (19) is removed, check the float (5). To do this, take the
upper section by the handle and turn it carefully so that the filter basket is facing
upwards. The float should move freely up and down (Fig.13).
WARNING! Never use alcohol, petrol or other cleaning agent. Never use caustic
agents to clean plastic parts.
TECHNICAL SPECIFICATIONS
MODEL
▪ Power input
▪ Maximum suction power
▪ Maximum power input for
a plugged-in power tool
▪ Tank capacity
▪ Tank material
▪ Dust bag capacity
▪ Maximum suction force
▪ Maximum air flow
▪ Air flow according to EN 60312
▪ Automatic mode with power tools
▪ Water drain
▪ Air-control handle
▪ Hose diameter
▪ Hose length
▪ Cable length
▪ Weight (EPTA procedure 01/2003)
▪ Protection class
▪ Safety class
▪ Noise emission (EN 60704):
A-weighted sound pressure level LpA
A-weighted sound power level LwA
ALS1020SF
1400W
1700W
2000 W
20 l
Stainless steel
20 l
18 kPa
58 l/s
31 l/s
Yes
Yes
Yes
Ø36 mm
2.5 m
4 m
7.1 kg
IP 44
I
76,2 dB(A)
89,6 dB(A)
ALS1030SF
1400W
1700W
2000 W
30 l
Stainless steel
30 l
18 kPa
58 l/s
31 l/s
Yes
Yes
Yes
Ø36 mm
2.5 m
4 m
7.8 kg
IP 44
I
76,2 dB(A)
89,6 dB(A)
ALS1045SF
1400W
1700W
2000 W
45 l
Stainless steel
30 l
18 kPa
58 l/s
31 l/s
Yes
Yes
Yes
Ø36 mm
2.5 m
4 m
11 kg
IP 44
I
76,2 dB(A)
89,6 dB(A)
4. MAINTENANCE
5. TECHNICAL SPECIFICATIONS
WARRANTY
The guarantee period for STATUS electric appliances is determined in the
guarantee card. Faults due to normal wear, overloading or improper handling will be
excluded from the guarantee. Faults due to defective materials implemented as well
as defects in workmanship will be corrected free of charge through replacement or
repair. The complaints for defective STATUS electric appliances will be recognized
if
the appliance is sent back to the dealer or is presented to the authorised warranty
TROUBLE SHOOTING
6. TROUBLE SHOOTING
EC Declaration of Conformity
We declare under our sole responsibility that this product fulfils all the relevant
provisions of the following directives and the harmonized standards:
2004/108/EC; 2006/95/EC; EN 60335-1; EN 60335-2-2; EN 62233; EN 55014-1;
EN 55014-2; EN 61000-3-2; EN 61000-3-3
The technical documentation kept by the manufacturer:
STATUS ITALIA S.R.L., via Aldo Moro, 14/A,
36060 - Pianezze (VI), ITALY
Caron Giacinto
Director
STATUS ITALIA S.R.L.
Replace the dust bag
Problem Probable cause
Corrective
The appliance doesn't
work
No power
Check the power supply
Functional fault in the
power cord, switch,
or motor
Test, repair or replace
the damaged part
Tank is full of liquid
Empty the tank
Dust is escaping from
the motor cover
The dust bag is missing
or damaged
Put in a dust bag or
replace it
Low suction power
and high motor
speed / vibrations
Dust bag is full
12
