13D-Link DIR-855 User Manual
Section 2 - Installation
The DIR-855 includes a Quick Router Setup Wizard CD. Follow the simple steps below to run the Setup Wizard to
guide you quickly through the installation process.
Insert the Quick Router Setup Wizard CD in the CD-ROM drive. The step-by-step instructions that follow are shown
in Windows
®
XP. The steps and screens are similar for the other Windows operating systems.
If the CD Autorun function does not automatically start on your computer, go to Start > Run. In the run box type
“D:\DIR855.exe” (where D: represents the drive letter of your CD-ROM drive).
When the autorun screen appears, click Start.
Getting Started
Note: It is reccomended to write down the SSID and Security Key, followed by the login password on the provided CD
holder.
Click Start
