D-Link DIR-855 [5/96] Product overview

1D-Link DIR-855 User Manual

Section 1 - Product Overview

Product Overview

Note: Using a power supply with a different voltage rating than the one included with the DIR-855 will cause damage and void the warranty for this

product.

D-Link DIR-855 Media Router

Power Adapter

Ethernet Cable

CD-ROM

Stand

Package Contents
