4-8
Chapter 4: BIOS setup
4.2.2 Menu bar
The menu bar on top of the screen has the following main items:
4.2.1 BIOS menu screen
Version 2.15.1234. Copyright (C) 2013 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Event Logs Boot Monitor Security Tool Exit
Set the Date, Use Tab to
switch between Data elements.
→←:
Select Screen
↑↓:
Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
BIOS Information
BIOS Vendor American Megatrends
BIOS Version 4.6.5.4
Compliancy UEFI 2.3.1; PI 1.2
BIOS Version 0212 x64
Build Date 3/20/2013
System Date [Mon 01/06/2013]
System Time [15:07:28]
Navigation keys
General help
Menu bar Conguration eldsMenu items
Main
For changing the basic system conguration
Advanced
For changing the advanced system settings
Event Logs
For changing the event log settings
Boot
For changing the system boot conguration
Monitor
For displaying the system temperature, power status, and
changing the fan settings
Security
For changing the security settings
Tool
For conguring options for special functions
Exit
For selecting the exit options
To select an item on the menu bar, press the right or left arrow key on the keyboard until the
desired item is highlighted.
