124

C. Disable the dial-up connection, if enabled.

Windows

1. Click Start > Internet Explorer

to launch the browser.

2. Click Tools > Internet options

> Connections tab.

3. Tick Never dial a connection.

4. Click OK when done.

NOTE: Refer to your browser's help feature for details on disabling the

dial-up connection.
