Motherboard Manual
40
POLISH
SPEC
Procesor
Sockel AM2+
AMD Sempron / Athlon / Athlon II / Phenom /
Phenom II Procesory
(Maksymalny Watt: 95W)
Architektura AMD 64 umożliwia przetwarzanie 32 i 64
bitowe
Obsługa Hyper Transport 2.0
FSB
Obsługa HyperTransport 2.0 o szerokości
pasma do 2 GT/s
Chipset
AMD 740G (A740G M2L+)
AMD 780L (A780LB)
AMD SB710
Pamięć
główna
Gniazda DDR2 DIMM x 2
Maks. wielkość pamięci 8GB
Każde gniazdo DIMM obsługuje moduły
256MB/512MB/1GB/2GB/4GB DDR2
Moduł pamięci DDR2 z trybem podwójnego kanału
Obsługa DDR2 533 / 667 / 800
Obsługa DDR2 1066 (by AM2+/AM3 CPU)
Brak obsługi Registered DIMM oraz ECC DIMM
Super I/O
ITE 8718F
Zapewnia najbardziej powszechne
funkcje Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Monitor H/W
Funkcja ITE "Smart Guardian"
Grafika
Zintegrowana w chipsecie AMD 740G
Maks. wielkość współdzielonej pamięci video wynosi
512 MB
Obsługa Avivo
IDE
Zintegrowany kontroler IDE
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
SATA
Zintegrowany kontroler Serial ATA
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
LAN
Realtek RTL 8102EL/8103EL/8106E 10 / 100 Mb/s z automatyczną negocjacją szybkości
Obsługa
audio HD
ALC662
5.1 kanałowe wyjście audio
Obsługa High-Definition Audio
Gniazdo PCI Express X16 x1
Gniazda
Gniazdo PCI x2
Złącze napędu dyskietek x1 Każde złącze obsługuje 2 napędy dyskietek
Złącze IDE x1 Każde złącze obsługuje 2 urządzenia IDE
Złącza
wbudowan
e
Złącze SATA x4 Każde złącze obsługuje 1 urządzenie SATA
