11
Catalyst 2960-S Switch Getting Started Guide
OL-19793-02
Catalyst 2960-S Switch Getting Started Guide
Managing the Switch
After completing Express Setup and installing the switch in your network, you
can use one of these options for further configuration:
• Device Manager
• Cisco Network Assistant
• Command-Line Interface
• Other Management Options
Device Manager
The simplest way to manage the switch is by using Device Manager in the switch
memory. This web interface offers quick configuration and monitoring. You can
access Device Manager from anywhere in your network through a web browser.
1. Launch a web browser on your PC or workstation.
2. Enter the switch IP address in the web browser, and press Enter. The Device
Manager page appears.
3. Use Device Manager to perform basic switch configuration and monitoring.
See the Device Manager online help for more information.
4. For more advanced configuration, download and run Cisco Network
Assistant, which is described in the next section.
Cisco Network Assistant
Cisco Network Assistant is a software program that you download from
Cisco.com and run on your
PC. It offers advanced options for configuring and
monitoring multiple devices, including switches, switch clusters, switch stacks,
routers, and access points. Cisco Network Assistant is free—there is no charge to
download, install, or use it.
1. Go to this Web address:
http://www.cisco.com/en/US/products/ps5931/tsd_products_support_series_
home.html.
