Epson surecolor sc-p6000 std [172/198] Archival matte paper
![Epson surecolor sc-p6000 std [172/198] Archival matte paper](/views2/1218372/page172/bgac.png)
Supported paper sizes
Size Borderless Calibration Mounter
A3
---S-B/A3+
A2
Archival Matte Paper
❏ Paper thickness: 0.2mm
Printer driver settings
Media Type Matte Paper - Archival Matte Paper
Type of black ink Photo Black (PK), Matte Black (MK)
ICC profile
SC-P9000 Series/SC-P7000
Series
LLK ink set:
❏ PK: SC-P9000_P7000_Series_LLK ArchivalMattePaper_PK.icc
❏ MK: SC-P9000_P7000_Series_LLK ArchivalMattePaper_MK.icc
V ink set:
❏ PK: SC-P9000_P7000_Series_V ArchivalMattePaper_PK.icc
❏ MK: SC-P9000_P7000_Series_V ArchivalMattePaper_MK.icc
SC-P8000 Series/SC-P6000
Series
❏ PK: SC-P8000_P6000_Series ArchivalMattePaper_PK.icc
❏ MK: SC-P8000_P6000_Series ArchivalMattePaper_MK.icc
Supported paper sizes
Size Borderless Calibration Mounter
A3
- ✓
-
S-B/A3+
A2
✓
*2
US-C
*1
*1 SC-P7000 Series/SC-P6000 Series is not supported.
*2 Only operations guaranteed. (Color measurement not guaranteed.)
Enhanced Matte Paper
❏ Paper thickness: 0.2mm
SC-P9000 Series/SC-P7000 Series/SC-P8000 Series/SC-P6000 Series User's Guide
Appendix
172
