SUBWOOFERS

 CS-SW100 CS-SW120 CP-SW100 CP-SW120

PeakPower(Watts) 800 1000 1000 1300

RatedPower(Watts) 200 250 250 325

FrequencyResponse 33Hz-1.2kHz 27Hz-1kHz 30Hz-1.2kHz 24Hz-1kHz

Impedance 4Ohms 4Ohms 4Ohms 4Ohms

Sensitivity 87dB 88dB 88dB 89dB

ConeMaterial PressedPaper PressedPaper PressedPaper PressedPaper

VoiceCoilType RoundWound RoundWound RoundWound RoundWound

 Copper Copper Copper Copper

MountingDepth 120mm(4-23/32”) 136mm(5-11/32”) 142mm(5-19/32”) 154mm(61/16”)

MountingDiameter 228mm 277mm 228mm 277mm

 (9”) (1015/16”) (9”) (1015/16”)

CS-SW100 CS-SW120 CP-SW100 CP-SW120

SPEAKER PARAMETERS

www.fusionelectronics.com

INSTALLATION GUIDELINES

Ensuretheaudiosystemisturnedoffbeforemakinganyconnectionstotheamplier,speakersorsourceunit.

Failuretodosocouldresultinpermanentdamagetotheaudiosystem.

Whenwiringthesubwooferensurethatthewireisprotectedfromsharpobjectsandalwaysuserubber

grommetswhenwiringthroughmetalpanels.Ensureallterminalsandconnectionsareprotectedfromthe

vehiclechassisandfromeachotherasfailuretodosocouldresultinpermanentdamagetotheaudiosystem.

Whenconnectingtheamplierandsubwooferensureyouconnectthepositiveandnegativeoutputwirefrom

theampliertothecorrespondingsubwooferterminals.

1) Ensurethereisadequateclearanceanddepthforthesubwoofertobemounted

2) Markout&cutthecorrectdiameterhole

3) Drilltheholesforthemountingscrews

4) Insertthesubwooferandafxwiththeappropriatescrews
