6.4. Weather

•The weather station indicates a trend as to how the values

for the outdoor temperature (8), room temperature (9) are

likely to develop over the next few hours.

Display Trend

Increasing

Constant

Decreasing

6.5. Maximum and minimum temperature values

•The base station automatically stores the maximum and

minimum outdoor/indoor temperature.

•Repeatedly press the MEM button (19) to switch between

the current temperature, minimum temperature (MIN)

and maximum temperature (MAX). The maximum and

minimum temperatures are displayed for 10 seconds.

•Press and hold the MEM button (19) for approx. 3 seconds

to reset the stored maximum and minimum values.

6.6 Low battery capacity

Measuring station

If the batteries need to be replaced, the symbol for low

battery charge will appear next to the outdoor

temperature display on the base device. Replace the batteries

immediately.

Base station

If the batteries need to be replaced, the symbol for low

battery charge will appear next to the time display on

the base device. Replace the batteries immediately.

Note – Replacing the batteries

•Note that the stations have to be resynchronised each

time after you change the batteries in the measuring

or base station.

•To do this, remove the batteries from the other station

and then reinsert them, or change them as required.

7. Care and Maintenance

Only clean this product with a slightly damp, lint-free cloth

and do not use aggressive cleaning agents. Make sure that

water does not get into the product.

8. Warranty Disclaimer

Hama GmbH & Co. KG assumes no liability and provides no

warranty for damage resulting from improper installation/

mounting, improper use of the product or from failure to

observe the operating instructions and/or safety notes.

9. Service and Support

Please contact Hama Product Consulting if you have any

questions about this product.

Hotline: +49 9091 502-115 (German/English)

Further support information can be found here:

www.hama.com

10. Technical Data

Base station

Measuring station

Power supply

3,0 V

2 x AA batteries

3,0 V

2 x AAA batteries

Measuring range

Temperature

-5°C – +50°C/

23°F – 122°F

-10°C – +60°C/

14°F – 140°F

Measurement

increments

Temperature

0,1°C / 0,2°F 0,1°C / 0,2°F

Temperature

measurement

cycle

~ 45 s~45 s

Radio-controlled

DCF clock

YesNo

Max. number

of measuring

stations

Frequency 433 MHz

Range ≤ 30 m

Note – Weekday

You can choose from German (DE), English (EN), Swedish

(SW), Dutch (DU), Spanish (SP), Italian (IT) or French (FR)

for the weekday display.

Setting the time zone

Note – Time zone

•The DCF signal can be received over long distances,

but always transmits the current Central European

Time in Germany. Make sure you account for the time

difference in countries with another time zone.

•If you are in Moscow, the time is 3 hours later than in

Germany. This means that you should set +3 for the

time zone. The clock then automatically sets the time to

3 hours after the DCF signal received or relative to the

manually set time.

Alarm

•In repeatedly press the ALARM ON/OFF button (18) to

display the different alarms. The respective alarm symbols

(12) / / and the corresponding alarm

time/time interval and/or OFF are displayed.

•Press and hold the ALARM ON/OFF button (18) for

approx. 3 seconds to set the alarm time of the alarm

displayed. The hours display/time interval starts to ash.

•Press the ▲ button (16) or the  button (14) to select

the hour for the alarm time/time interval and conrm your

selection by pressing the ALARM ON/OFF button (18).

The minutes display begins to ash. The early alarm is

already activated after conrming the time interval.

•Repeat the process to set the minutes for the alarm time.

•Press the ALARM ON/OFF button (18) repeatedly to also

set the other alarm mode or return to the time display (10).

•If you do not make an entry for 2 minutes, you

automatically exit the setup mode.

Note – Alarm

•When activated, the weekday alarm only triggers an

alarm on weekdays (Monday to Friday). The alarm

symbol (12)

is displayed if this alarm is activated.

•When activated, the once-only alarm only triggers an

alarm once. The alarm symbol (12) is displayed

if this alarm is activated. This alarm is automatically

deactivated after the alarm has sounded.

•When activated and when the outside temperature is <

0°C/ 32°F, the early alarm triggers an alarm 15, 30, 45,

60 or 90 minutes before the actual alarm ( and/or

). The alarm symbol (12) is displayed if this

alarm is activated.

•To determine whether the alarm should be triggered,

the set alarm time is compared to the currently

displayed time (whether normal or time zone-shifted).

•In the corresponding display, press the ▲ button (16) or

the  button (14) to activate/deactivate the corresponding

alarm.

The alarm symbol (12) will appear/not appear.

Note – Early alarm

The early alarm can only be activated if at least one of

the two alarm functions ( / ) has already been

activated.

•If the alarm is triggered, the alarm symbol (12) will begin

to ash and an alarm will sound.

•Press the ALARM ON/OFF button (18) to stop the alarm.

Otherwise, it will stop automatically after 2 minutes.

Otherwise, after two minutes snooze mode is activated

automatically.

Note – Snooze function

•While the alarm signal is sounding, press the SNOOZE

button (20) to activate the snooze function. The alarm

symbol (12) begins to ash in the display. The alarm

signal is stopped for 8 minutes, after which it will

sound again.

•The snooze function can be activated three consecutive

times.
