Statement 15:

CAUTION:

Make sure that the rack is secured properly to avoid tipping when the server

unit is extended.

Statement 17:

CAUTION:

The following label indicates moving parts nearby.

Statement 26:

CAUTION:

Do not place any object on top of rack-mounted devices.

Statement 27:

CAUTION:

Hazardous moving parts are nearby.

Statement 35:
