16
Reference
System Cabling Diagram
For system with 16 x 2.5” hard drive bay:
NOTE: A second SSD is supported when the optical drive is NOT in use. For cable routing, please refer to Page 17.
Server
Board
Power
Supply
Optical Drive
SAS
Expander
BBU
SSD
Intel
®
Integrated
RAID Module
8 x 2.5" HSBP 8 x 2.5" HSBP
Front Panel
I
2
C
I
2
C
Front Panel Video
Front Panel USB
Mount on Air Duct
A
C D E F
B
