15
Specifications
Specifications
CPU
Supports 6th Gen Intel
®
Core
™
i3/i5/i7 processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
B150 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
Supports DDR4 2133 MHz*
y Dual channel memory architecture
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)**
* Please refer to www.msi.com for more information on compatible memory.
** DDR4 2133 MHz and higher memory modules will only run at maximum of
DDR4 2133 MHz on XMP mode due to Intel
®
chipset limitation.
Expansion Slots
y 1x PCIe 3.0 x16 slot
y 2x PCIe 3.0 x1 slots
Onboard Graphics
y 1x HDMI
™
port, support a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, support a maximum resolution of
1920x1200@60Hz
Storage
Intel
®
B150 Chipset
y 6x SATA 6Gb/s ports
y 1x M.2 slot (Key M)*
Supports up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
Supports PCIe 3.0 x4 NVMe Mini-SAS SSD with Turbo U.2
Host Card**
* SATA1 port will be unavailable when installing the M.2 SATA module in M.2
slot.
** The Turbo U.2 Host Card is not included, please purchase separately.
USB
y Intel
®
B150 Chipset
1x USB 3.1 Gen1 Type-C port on the back panel
5x USB 3.1 Gen1 (SuperSpeed USB) ports (3 ports on the
back panel, 2 ports available through the internal USB
connector)
6x USB 2.0 (High-speed USB) ports (2 ports on the
back panel, 4 ports available through the internal USB
connectors)
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
Continued on next page
