Stanley stsp125 [8/56] English

ENGLISH

(Original instructions)

Warning! Always switch off the tool and then the

power supply when work is ﬁnished.

Cutting (Fig. E)

• Align the front edge of the base with the cutting

• Line on the workpiece.

• Hold the tool ﬁrmly.

• Set the base on the workpiece to be cut without the

wheel making any contact.

• Turn the tool on and wait until the wheel attains full

speed.

• Move the tool forward over the workpiece surface,

advancing smoothly until the cut is completed.

• Keep the cutting line straight.

Warning! This tool should only be used on horizontal

surfaces.

• Be sure to move the tool gently forward, in a straight

line.

• Forcing, or exerting excessive pressure, or allowing the

wheel to bend, pinch or twist in the cut can cause the

motor to over heat and tool to kick back dangerously.

• When the depth of cut is over 20mm deep, make 2 or 3

separate cuts to prevent motor failure.

Maintenance

Your STANLEY power tool has been designed to operate

over a long period of time with minimal maintenance.

Continuous satisfactory operation depends upon proper tool

care and regular cleaning. Do not repair the tool yourself.

Please send your tool to authorized STANLEY service

centers for regular maintenance and service, or when a

signiﬁcant change in performance is observed.

Carbon brushes (Fig. F)

• Remove and check carbon brushes regularly.

• Replace when they have worn down to about 6mm or

less.

• Keep carbon brushes clean for free movement in the

holder. Both carbon brushes should be replaced at the

same time.

• Use only STANLEY carbon brushes.

• Use a slotted screwdriver to remove brush caps (5).

• Remove worn brushes, insert new ones, and secure the

brush caps.

Cleaning

Warning! Unplug the tool before you use a cloth

to clean the housing. With the motor running,

blow dirt and dust out of all air vents with dry air at least

once a week. Wear safety glasses when performing this.

Exterior plastic parts may be cleaned with a damp cloth and

mild detergent. Although these parts are highly solvent

resistant, NEVER use solvents.

Tool Care

Avoid overloading the power tool. Overloading will result in a

considerable reduction in speed and efﬁciency and the tool

will over heat. In this case, run the power tool at no load for a

minute or two until cooled to normal working temperature by

the built in fan. Switching your tool on and off whilst under

load will considerably reduce the life of the tool.

Important

To ensure product safety and reliability, repairs, maintenance

and adjustment (other than those listed in this manual)

should be performed by authorized service centers or other

qualiﬁed organizations, always using identical replacement

parts. Unit contains no user serviceable parts inside.

Accessories

The performance of any power tool is dependent on the

accessory used. STANLEY accessories are engineered to

high quality standards and are manufactured from the best

materials. Stringent tests are performed before the

accessories are launched in the market. They are designed

to enhance the performance of power tools.

Purchase STANLEY accessories to bring your STANLEY

power tools to greater performance. Recommended

STANLEY accessories are available at your local authorized

dealers or service centers. STANLEY offers a large selection

of accessories at your local dealer or authorized service

center.
