Al-Ko 112927 GTLi 18V Comfort [2/18] Spec no inr18650 13q version no 1

-SAMSUNG SDI Confidential Proprietary –

Spec. No.

INR18650-13Q Version No.

1.0

1. Scope

This product specification has been prepared to specify the rechargeable lithium-ion cell

('cell') to be supplied to the customer by Samsung SDI Co., Ltd.

2. Description and Model

2.1 Description Cell (lithium-ion rechargeable cell)

2.2 Model INR18650-13Q

3. Nominal Specifications

Item Specification

3.1 Nominal Capacity 1300mAh (260mA, 2.5V discharge)

3.2 Minimum Capacity 1250mAh(260mA, 2.5V discharge)

3.3 Charging Voltage

4.2 ±0.05 V

3.4 Nominal Voltage

3.6V

3.5 Charging Method

CC-

(constant voltage with limited current)

3.6 Charging Current Standard charge: 0.91

3.7 Charging Time Standard charge : 150min

3.8 Max. Charge Current

4A(ambient temperature 25℃)

3.9 Max. Discharge Current

(continuous)

15A(ambient temperature 25℃)

3.10 Max. Discharge Current

(Pulse)

30A 1sec

3.11 Discharge Cut-off Voltage

2.5V

3.12 Cell Weight 43.0g max

3.13 Cell Dimension

Height : 65.00mm max

Diameter : 18.40mm max

3.14 Operating Temperature

Charge : 5 to 40℃

Discharge: -20 to 60℃

3.15 Storage Temperature

1 year : -20~25℃(1*)

3 months : -30~45℃(1

1 month : -30~60℃(1*)

Note (1): If the cell is kept as ex-factory status (50% of charge),

the capacity recovery rate is more than 80%.
