Belkin F7D3302 [28/37] Troubleshooting support and warranty

TROUBLESHOOTING, SUPPORT, AND WARRANTY

I am having difficulty setting up Wired Equivalent

Privacy (WEP) security on my Router.

1. Log in to your Router. Visit http://router/ with your web browser.

Click on the “Login” button in the top right-hand corner of the

screen. You will be asked to enter your password. If you have never

set a password, leave the “Password” field blank and click “Submit”.

2. Click “Wireless” in the left-hand menu. Then

click “Security” just below that.

3. Select the “128-bit WEP” option.

4. You may type in a WEP key manually, or generate one from

a passphrase. Type a phrase in the “Passphrase” field and

click the “Generate” button. A WEP key is composed of 26

hexadecimal digits (0–9, A–F.. For example, C3 03 0F AF

4B B2 C3 D4 4B C3 D4 EE 74 is a valid 128-bit WEP key.

5. Click “Apply Changes” to finish. Your wireless

activity is now encrypted. Each computer using your

wireless network will need to use the new key.

Note: If you are configuring the Router over a wireless

connection, you will have to re-connect to the

Router after changing any security settings.

Note: Some older networking hardware supports

only 64-bit WEP encryption. If your older computers

cannot connect to your network, try 64-bit WEP.
