Condtrol unix360pro 1-2-108 [6/15] Condtrol unix 360 pro

User manual

CROSS LINE LASER

CONDTROL UniX 360 Pro

User manual

CROSS LINE LASER

CONDTROL UniX 360 Pro

oPerAtion

Remove the battery cover. Insert the batteries, observing correct polarity.

Put the battery cover back. Place an instrument on a tripod or on a firm and stable surface.

To switch on an instrument, move compensator (8) to the right position to release. By consecutive

pressing of the Mode switching button (2) the instrument is switched to the different operating

modes. To use Electronic Receiver press button (3) switch on/off pulse mode.

The following 2 operating modes are available:

- Operation with the automatic compensation to project horizontal and vertical laser lines

and planes. The compensator automatically aligns instrument’s position within the range of

compensation ±5°. The laser beam starts to blink along with a sound alarm when the instrument is

out of the range of the automatic compensation.

- Without Automatic Levelling mode to construct inclined planes.

To switch on/off automatic levelling press and hold (no less than 2 sec.) button (3). At the switched

off automatic compensation you can freely hold the instrument in your hand or place it on a suitable

surface. Laser beams will work stable without blinking, no sound alarm to signal. To switch off

the instrument and/or prepare it for transportation move compensator (8) to the left position, the

levelling unit is blocked. When the battery indicator (4) and laser planes are blinking, the batteries

must be replaced.

sAFety reGulAtions

The user manual should be read carefully before you use the product for the first time. Unintended

use of the product can be dangerous for human’s health and cause serious injury. Keep this user

manual. If the product is given to somebody for temporary use, be sure to enclose user manual to it.

- Do not misuse the product

- Do not remove warning signs and protect them from abrasion, because they contain information

about safe operation of the product.

The device belongs to laser product class 2 in

accordance with

EN 60825-1 with a 630-670 nm wavelength.

- Do not look into the laser beam or its reflection, with unprotected eye or through an optical

instrument. Do not point the laser beam at people or animals without the need. You can dazzle them.

- To protect your eyes close them or look aside.

- It is prohibited to disassemble or repair the product yourself. Intrust product repair to qualified

personnel and use original spare parts only.

- Do not use the product in explosive environment, close to flammable materials.

- Avoid heating the batteries to avoid the risk of explosion and electrolyte leakage. In case of liquid

contact with skin, wash it immediately with soap and water. In case of contact with eyes, flush with

clean water during 10 minutes and consult the doctor.
