User manual
CROSS LINE LASER
CONDTROL UniX 360 Pro
User manual
CROSS LINE LASER
CONDTROL UniX 360 Pro
SPECIFICATIONS
Working range/with detector 40 m / 80 m*
Leveling accuracy ± 0,2 mm/m
Self-leveling range ±5°
Leveling duration, typically <3 s
Receiver mode √
inclined planes mode √
Operating temperature +5°с…+40°с
Storage temperature -30°с…+80°с
Relative air humidity, max 90%
Laser type 635 nm, <1mW
Laser class 2
Tripod mount 1/4''
Batteries 3x1,5V LR6 (AA)
Operating life time 10 h
Weight 620 g
Dimensions 140х104х125mm
* An operating range can be different from the stated above subject to light conditions.
ACCURACY CHECK
Checking of the horizontal line
Checking of the horizontal line
For this check, a free measuring distance of 5 meters on a firm surface between two walls A and B
is required.
1. Mount the instrument onto a tripod or place it on a firm and level surface close to wall A (see
figure I). Switch on the instrument. Select cross-line operation with automatic leveling
Direct the laser against the close wall A and allow the instrument to level in. Make A1 mark at the
centre of the point where the laser lines cross each other on the wall (point I).
Mark point B on the opposite wall.
2. Turn the instrument by 90°. Check whether the horizontal line is in level with point B1 within
±1 mm (see figure J). If deviation between the laser line and the B1 mark is greater than ±1 mm,
apply to service centre.
3. Repeat step 2 for 2 more times, turning the instrument in one direction.
4. Without turning the instrument, position it close to wall B. Make B2 mark at the centre of the
point where the laser lines cross each other on the wall (B1 and B2 marks should be placed on the
same Vertical line) (see figure K)
5. Turn the instrument by 180° and direct it against the wall A, place A2 mark for the cross point of
the laser lines on the wall (see figure L). (B1 and B2 marks should be placed on the same Vertical
line).
6. Check the distance dA, dB between marked points A1, A2 and B1, B2 accordingly (see figure L).
When the maximum deviation exceeds 2 mm, you should contact CONDTROL service centre.
Checking of the vertical line
Place the instrument at a distance of 1,5m from the instrument (see figure M).
Fix plumb bob on the wall, making sure that the bob can swing free.
Switch on the device and align the vertical laser to the plumb line.
Acceptable deviation between the laser line and the plumb line is not greater than ±0.2 mm per 1m of
the plumb bob length (for the 2.5m plumb bob, acceptable deviation is 0.5mm).
