17
AC Corinte
Technical specifications | Thermozone AC Corinte E with electrical heat 3
Type Output
steps
[kW]
Airflow
[m
3
/h]
∆t
*2
[°C]
Sound
level
*3
[dB(A)]
Voltage
motor
[V]
Voltage
heat
[V]
Amperage
motor
[A]
Amperage
heat
[A]
Height/
Length
[mm]
Weight
[kg]
ACC10E
*1
0/6/9 950/1900 29/14 44/61 230V~ 400V3~ 2,2 8,7/13,0 1000 47
ACC15E
*1
0/8/12 1350/2600 27/14 45/62 230V~ 400V3~ 2,9 11,5/17,3 1500 63
ACC20E 0/12/18 1980/3800 28/14 47/64 230V~ 400V3~ 4,3 17,3/26,0 2000 95
ACC25E 0/12/18 2340/4500 23/12 48/65 230V~ 400V3~ 5,1 17,3/26,0 2500 110
ACC30E 0/16/24 2660/5100 27/14 48/65 230V~ 400V3~ 5,8 23,1/34,6 3000 126
*
1
) ACC1000E and ACC1500E is available only for horizontal mounting.
*
2
) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*
3
) Conditions: Distance to the unit: 5 metres. Directional factor: 2. Equivalent absorption area: 200 m
2
.
Technical specifications | Thermozone AC Corinte WL with water heat, coil for low tempered water <80/60 °C 2
Type Output
*2
[kW]
Airflow
[m
3
/h]
∆t
*2,3
[°C]
Water
volume
[l]
Sound level
*4
[dB(A)]
Voltage
motor
[V]
Amperage
[A]
Height/
Length
[mm]
Weight
[kg]
ACC10WL
*1
19 950/1900 42/35 2,0 44/61 230V~ 2,1 1000 47
ACC15WL
*1
29 1350/2600 41/34 3,2 45/62 230V~ 2,9 1500 63
ACC20WL 42 1980/3800 40/33 4,3 47/64 230V~ 4,3 2000 95
ACC25WL 52 2340/4500 41/34 5,4 48/65 230V~ 5,0 2500 110
ACC30WL 60 2660/5100 38/31 6,6 48/65 230V~ 5,7 3000 126
Technical specifications | Thermozone AC Corinte WH with water heat, coil for high tempered water >80/60 °C 2
Type Output
*2
[kW]
Airflow
[m
3
/h]
∆t
*2,3
[°C]
Water
volume
[l]
Sound
level
*4
[dB(A)]
Voltage
motor
[V]
Amperage
[A]
Height/
Length
[mm]
Weight
[kg]
ACC10WH
*1
11 950/1900 26/20 1,1 44/61 230V~ 2,1 1000 47
ACC15WH
*1
17 1350/2600 26/20 1,9 45/62 230V~ 2,9 1500 63
ACC20WH 24 1980/3800 25/19 2,5 47/64 230V~ 4,3 2000 95
ACC25WH 30 2340/4500 25/23 3,3 48/65 230V~ 5,0 2500 110
ACC30WH 35 2660/5100 23/17 3,9 48/65 230V~ 5,7 3000 126
*
1
) ACC1000W and ACC1500W is available only for horizontal mounting.
*
2
) Applicable at water temperature 80/60 °C, air temperature in +15 °C.
*
3
) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*
4
) Conditions: Distance to the unit: 5 metres. Directional factor: 2. Equivalent absorption area: 200 m
2
.
Protection class AC Corinte E/W (IP20).
CE compliant.
