5
E N G L I S H
– To unwind the cord fast turn the upper
hook (9) clockwise or counterclockwise and
remove the power cord.
Note: If necessary, you can adjust the power
cord length winding the excessive cord around
the cord storage (9) hooks.
– Press the ON/OFF button (6) to switch the
vacuum cleaner on.
– During the operation of the unit you can con-
trol the suction power by turning the control
knob (5).
– After room cleaning press the ON/OFF but-
ton (6), set the vacuum cleaner to the vertical
storage position and unplug it.
– To wind the power cord use the cord stor-
age (9).
Using the turbo brush
You can use the turbo brush (1) for cleaning floors
and carpets with medium and low pile, it is per-
fect for removing pet hair from carpets.
The cylindrical hard-bristled brush is brought to
rotation by the air flow, its bristles comb out pet hair
thoroughly and sweep motes out of the carpet pile.
Note:
– Do not use the turbo brush for cleaning car-
pets with high fringe and pile of more than
15 mm to avoid carpet damaging by brush
rotation.
– Do not run the turbo brush over the wires and
switch the vacuum cleaner off right after the
cleaning is completed.
CLEANING THE VACUUM CLEANER
It is recommended to clean the vacuum cleaner
after every use. Before cleaning the vacuum
cleaner, switch it off by pressing the ON/OFF
button (6), set the vacuum cleaner to the vertical
storage position and unplug it.
Cleaning the dust bin (2), the inlet filter (12)
and the HEPA filter (13).
– To remove the dust bin (2) pull the lock (3) and
remove the dust bin (2).
– Take the HEPA filter (13) by both sides and
remove it from the dust bin (2) together with
the inlet filter (12).
– Remove dust and garbage from the inlet fil-
ter (12) with a suitable brush.
– Take the HEPA filter (13) by both sides and
remove it from the inlet filter (12). Remove
dust and garbage from the HEPA filter with a
suitable brush.
– Remove accumulated dust and garbage from
the dust bin (2) to a trash bin.
– Wash the inlet filter (12), the HEPA filter (13)
and the dust bin (2) under a warm water jet
and dry them thoroughly.
– Install the HEPA filter (13) into the inlet fil-
ter (12).
– Install the inlet filter (12) with the installed
HEPA filter (13) into the dust bin (2).
– To install the dust bin (2) back to its place
match the ledge on the bottom part of the
dust bin (2) with the groove on the vacuum
cleaner body (10) and insert the dust bin (2)
into the unit body (10) until bumping.
Cleaning of the turbo brush (1)
– Remove the turbo brush (1) from the brush
setting place (11), clean the turbo brush (1)
and install it back to its place.
– Clean the rotating brush as it becomes dirty.
– You can easily remove threads or long hair
wound up around the brush by cutting them
with scissors preliminary; be careful not to
damage the bristles of the brush.
Vacuum cleaner body (10)
• Wipe the vacuum cleaner body (10) with a
soft, slightly damp cloth and then wipe it dry.
• Do not immerse the vacuum cleaner
body (10), the power cord and the power plug
of the unit into water or other liquids. Provide
that no liquid gets inside the vacuum cleaner
body (10).
• Never use solvents or abrasives to clean the
vacuum cleaner and the accessories.
Cleaning the outlet filter
Clean the outlet filter as it becomes dirty, but no
less than once a month.
• Remove the outlet filter grid by pressing the
lock (4) and pulling it.
• Remove the outlet filter from the grid and
wash it with warm water, dry carefully and
install back to its place.
• Install the outlet filter grid back to its place
until the lock (4) clicking.
STORAGE
• Before taking the vacuum cleaner away for
long term storage, clean its body (10), the
dust bin (2) flask, the filters (12, 13) and the
turbo brush (1).
IM VT-8104.indd 5 16.09.2016 17:22:10
