- 6 -
Box Contents
5 GA-X99-UD4P motherboard
5 Motherboard driver disk
5 User's Manual
5 Quick Installation Guide
5 Four SATA cables
5 I/O Shield
5 One 2-Way SLI bridge connector
5 Two 3-Way SLI bridge connectors(GC-3SLI-X99andGC-3SLI)
5 One 4-Way SLI bridge connector
5 One 2-Way CrossFire bridge connector
5 One1to3powercable(2x4ATX12V)
Optional Items
2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)
eSATAbracket(PartNo.12CF1-3SATPW-4*R)
3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
