START UP

Keypad

1) Reference setting / Backlight

2) Addition / Timer

3) Area / Volume

4) ON / Measure / Continious measurements

5) Pythagorean measure

6) Subtraction / Measuring units

7) Clear / OFF

Display

1. Area / volume/ Pythagorean

2. Reference (front/rear)

1. Laser ON

2. Battery display

3. Timer

4. Units with exponents ( 2/3 )

5. Line 1

6. Line 2

7. Main Line

Inserting / Replacing Batteries

Remove the battery cover, insert the battery correctly. Pay

attention to correct polarity. Close the battery compartment.

Replace the battery when symbol constantly blinks in the dis-

play. Batteries should be removed in case of danger of corro-

sion, if the device will not be used for a long time.

MENU FUNCTIONS

Swtich on and off

Press the button (1) to switch on the instrument and laser.

Press and hold key for about 2 seconds to start continuous

measuring.

The device also switches off automatically after 3 minutes of

inactivity i.e. no key is pressed within that interval.

To switch off the instrument press and hold button (7) 2 sec.

Reference Setting

Default reference setting is from the rear of the device.

Press the button (1) to set the reference from the front or the

rear. When the end-piece is folded out fully, the reference
