SABERTOOTH P67 specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
2nd Generation Core™ i7 / Core™ i5 /Core™ i5 /
Core™ i3 ProcessorsProcessors
Supports 32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel CPU support list
Chipset Intel
®
P67 Express Chipset
Memory 4 x DIMM, max. 32GB*, DDR3 1866 / 1800 / 1600 / 1333 /
1066 MHz, non-ECC, un-buffered memory Dual channel
memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* The max. 32GB memory capacity can be supported with DIMMs
of 8GB (or above). ASUS will update QVL once the DIMMs are
available on the market.
** Due to CPU behavior, DDR3 1800 MHz memory module will
run at DDR3 1600 MHz frequency as default.
*** Hyper DIMM support is subject to the physical characteristics
of individual CPUs. Some hyper DIMMs only support one
DIMM per channel. Please refer to Memory QVL for details.
**** Refer to www.asus.com or this user manual for the Memory
QVL (Qualied Vendors Lists)
Expansion slots 2 x PCI Express 2.0 x16 slots (single at x16 or dual at x8/x8 mode)mode)
3 x PCI Express 2.0 x1 slots
1 x PCI slot
Multi-GPU support Supports NVIDIA
®
Quad-GPU SLI™ TechnologyQuad-GPU SLI™ Technology SLI™ Technology
Supports ATI
®
Quad-GPU CrossFireX™ Technology
Storage Intel
®
P67 Express Chipset
- 2 x SATA 6.0 Gb/s ports (brown)
- 4 x SATA 3.0 Gb/s ports (black)
- Intel
®
Rapid Storage Technology supports SATA RAID 0, 1,
5, and 10
Marvell
®
PCIe SATA 6.0 Gb/s controller
- 2 x SATA 6.0 Gb/s ports (gray)
JMicron
®
JMB362 SATA controller
- 1 x Power eSATA 3.0 Gb/s port (green)
- 1 x eSATA 3.0 Gb/s port (red)
LAN Intel
®
82579 Gigabit LAN controller – Dual interconnect between
the Integrated LAN controller and Physical Layer (PHY)
Audio Realtek
®
ALC892 8-channel High Denition Audio CODEC
- Absolute Pitch 192khz/24bit True BD Lossless Sound
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-Streaming and
Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
