ASUS SABERTOOTH P67 2-3
Chapter 2
Layout contents
Connectors/Jumpers/Slots Page
1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-21
2. CPU, chassis, power, and assistant fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1, 3-pin CHA_FAN2,
3-pin PWR_FAN, 3-pin ASST_FAN)
2-20
3. LGA1155 CPU socket 2-4
4. DDR3 DIMM slots 2-5
5. MemOK! switch 2-13
6. USB 3.0 connector (20-1 pin USB3_34) 2-18
7. Marvell
®
Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_E1/E2 [gray])
2-17
8. Intel
®
P67 Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_1/2 [brown])
2-15
9. Intel
®
P67 Serial ATA 3.0 Gb/s connectors
(7-pin SATA3G_3–6 [black])
2-16
10. Clear RTC RAM (3-pin CLRTC) 2-12
11. System panel connector (20-8 pin PANEL) 2-23
12. Serial port connector (10-1 pin COM1) 2-17
13. Standby power LED (SB_PWR) 2-14
14. USB 2.0 connectors (10-1 pin USB910, USB1112, USB1314) 2-18
15. IEEE 1394a port connector (10-1 pin IE1394_2) 2-19
16. Digital audio connector (4-1 pin SPDIF_OUT) 2-19
17. Front panel audio connector (10-1 pin AAFP) 2-21
