Asus RT-AC1200HP [12/129] Wireless connection

2. Using the bundled network cable, connect your computer to

your wireless router’s LAN port.

IMPORTANT! Ensure that the LAN LED is blinking.

3 Using another network cable, connect your modem to your

wireless router’s WAN port.

4. Insert your modem’s AC adapter to the DC-IN port and plug it

to a power outlet.

1.6.2 Wireless connection

Modem

To set up your wireless router via wireless connection:

1. Insert your wireless router’s AC adapter to the DC-IN port and

plug it to a power outlet.

2 Using the bundled network cable, connect your modem to

your wireless router’s WAN port.
