Medeli DD 60 [10/16] 页 10

Play the Pads

Pad Names

Pad 1

Pad 2 Pad 3

Pad 4

Assign a Voice to Individual Pads

1、Select a Rhythm

The Digital Drum has a total of 70 percussion sounds and 10 sound

effects that can be assigned to each of the 4 drum pads.

Rotate the DIAL to select a Rhythm that you want to assign the pads.

2、Press the [PAD ASSIGN] button

Press the [PAD ASSIGN] button. PAD ASSIGN indicator appear on the

display and the indication light below Pad 1 light up.

4、Select a Percussion

You can select the voice by striking the pad repeatedly until you reach

the voice that you desired.

5、Press the PAD ASSIGN Button

When you have finished selecting your desired percussion sound,

press the [PAD ASSIGN] button to confirm.

6、Play the Pads

Now you can play your drum with the assigned drum pad.

Repeat steps 2-5 if you want to assign another drum pad.

Note:

The most recently assigned percussion sounds will overwrite the

percussion sounds assigned previously.

3、Select a Pad

Strike the Drum Pad that you want to assign once, for example, Drum

Pad 2, the indicator below Pad 2 light up, and the display show the

current .percussion and effect sounds number
