10
1
2
3
4
Press PATCH+ and PATCH- switches
simultaneously to enter the tuner mode.
The LCD displays .
Hold the two switches longer to enter
the MUTE status. The LCD displays
. You can tune your guitar strings
without sound.
'TUNER'
'MUTE'
Hold the two
switches longer
PATCH+/
BYPASS
PATCH-
MUTE
BANK
Press
simultaneously
Show the note which is
closest to the current pitch.
Imply the string has
the correct tuning.
Reference
pitch
PATCH+/
BYPASS
PATCH-
TUNER
-----
BANK
BANK
BANK
PAT C H
PAT C H
PAT C H
PAT C H
Tuning with the stings
The LCD will display the pitch : A, B,
C, D, E, F, G and b.
Symbols > or < imply whether the
tune is flattened or sharpened .
The distance in the middle implies the
degree of flatless or sharpness. When
the display shows >|< , that means
the string has a correct tuning.
The tuner function will activate under
bypass or mute status. Press PATCH+
or PATCH- to exit from the tuner mode.
Dial the knob to change the reference
pitch. The frequency of A (the middle
A of a piano) played by an instrument
(such as a piano) that provides the
pitch to which the other instruments
refer in tuning before a performance
begins is called the reference pitch.
The default reference pitch is set to
440 Hz.
TYPE/PARA/M.VOL
Rotate to change the reference pitch
