Medeli GP 120 [11/24] The unit has a built in rhythm function which plays realistic drum sounds in various patterns
![Medeli GP 120 [11/24] The unit has a built in rhythm function which plays realistic drum sounds in various patterns](/views2/1239532/page11/bgb.png)
11
1
2
Dial the knob to PLAY, press
button, the indicator PLAY on the
LCD is lighted.
Press the dial to adjust the parameter,
rhythm pattern, tempo or rhythm
volume.
Dail the knob to set the value of the
parameter.
Press the again to return to
the previous status.
-BANK+
STORE
TAP
PLAY
NG
COMP
WAH
STOMP
AMP
EQ
CAB
MOD
DELAY
REVERB
P. F.
8beat
Tempo
Level
SRock
8beat
Set to PLAY
Press the dial
Rotate the dial
BANKPATCH
LED
Flashing
The unit has a built-in rhythm
function which plays realistic
drum sounds in various patterns.
TYPE/PARA/M.VOL
TYPE/PARA/M.VOL
3
4
If no action of the rhythm is taken
in 8s, the LCD will redisplay the patch
name.
