12
-BANK+
-BANK+
STORE
STORE
TAP
TAP
PLAY
NG
COMP
WAH
STOMP
AMP
EQ
CAB
MOD
DELAY
REVERB
P. F.
P. F.
8beat
Set to PLAY
BANKPATCH
LED
Flashing
LED
Flashing
To continuously change the rhythm
tempo, firstly press the dial switch
to set the tempo as the adjusting
parameter. Then dial the knob.
To manually adjust the rhythm tempo,
hit the tap button at least two times
in the desired interval.
1
2
The rhythm tempo can be adjusted
in the range of 40 --- 250 bpm
(beats per minute)
Tempo
Tempo
Press the dial
Press at least two times.
TYPE/PARA/M.VOL
At the first hit of the TAP button, the
current tempo value is shown on the LCD.
The unit then automatically detects the
interval of the second and subsequent
keypresses and sets the tempo
accordingly.
