Motor

The motor is controlled by an ON/OFF switch or push button which is mounted on the

motor below the fuel tank.

The m otor speed is controlled by a remote throttle lever which is mounted on the

machine handle.

Honda and Kama motors are fitted with an oil alert device which will stop the motor or

prevent starting when the crankcase oil level falls below a safe level.

Drive belt

Tension of the drive belt is adjustable. Loosen the four nuts on the bolts which secure the

motor to the baseplate. Adjust the set screws which bear against the motor crankcase to

achieve the required belt tension. Ensure that the four nuts and the s

et screw locknuts

are tightened after adjustment.

ACCESSORIES

Thansport Trolley - facilitates handling. Hooks into the baseplate. Fitted with 200mm

rubber tyres.

FOR SAFETY OPERATION

! This safety alert symbol identifies important safety messages through out this manual

and on the machine.

When you see this symbol, carefully read the message that follows. Your safety is at

stake!

Foreword:

It is important to read this manual carefully so that you will fully understand the

operational characteristics and performance of the plate compactor, Proper maintenance

procedures will insure long life and top performance of the unit.

Safety:

This section outlines basic safety procedures that apply to the operation, maintenance

and adjustment of the plate compactor. This unit is designed as a powerful, productive

machine that should be operated with respect and caution.

Misuse or carelessness can result in serious injury or property damage. Or both. Safety

precautions must be observed at all times.

Operator Qualifications:

Before operating this equipment, an individual should read this manual. Whenever

possible, he should beshown how to operate the unit by an experienced operator.
