TSC P200 [8/48] Printer optional features
![TSC P200 [8/48] Printer optional features](/views2/1244110/page8/bg8.png)
3
Text, bar code, graphics/image printing (Please refer to the
TSPL/TSPL2 programming manual for supporting code
page)
Supported bar code
Supported image
1D bar code
2D bar code
BITMAP,
BMP,
PCX
(Max. 256 colors
graphics)
Code 39,
Code 93,
Code128UCC,
Code128 subsets
A,B,C, Codabar,
Interleaved 2 of 5,
EAN-8, EAN-13,
EAN-128,
UPC-A, UPC-E,
EAN and UPC 2(5)
digits add-on, MSI,
PLESSEY,
POSTNET,
China POST,
GS1 DataBar,
Code 11
PDF-417,
Maxicode,
DataMatrix,
QR code,
Aztec,
GS1 DataBar
Composite code
○
○
1.2.2 Printer Optional Features
The printer offers the following optional features.
Product option feature
User
options
Dealer
options
Factory
options
LCD display (graphic type, 128x64 pixel) with back
light
-
-
○
Internal Ethernet print server (10/100 Mbps) interface
-
-
○
Peel-off module
-
○
-
Guillotine cutter module (Full cut and partial cut)
Paper thickness: 0.06~ 0.19mm, 500,000 cuts
0.20~ 0.25mm, 200,000 cuts
Note:
Except for the linerless cutter, all regular/heavy
duty/care label cutters DO NOT cut on media with glue.
-
○
-
External roll mount with 3” core (8.4 OD) label spindle
○
Extended plate for external roll mount
○
Bluetooth module (RS-232C interface)
○
-
-
KP-200 Plus keyboard display unit
○
-
-
KU-007 Plus programmable smart keyboard display
unit
○
-
-
HCS-200 long rang CCD scanner
○
-
-
