2. Operations Overview
2.1 Unpacking and Inspection
This printer has been specially packaged to withstand damage during shipping. Please
carefully inspect the packaging and printer upon receiving the bar code printer. Please
retain the packaging materials in case you need to reship the printer.
Unpacking the printer, the following items are included in the carton.
If any parts are missing, please contact the Customer Service Department of your
purchased reseller or distributor.
One printer unit (MH240, MH240T, or MH240P Series)
One quick installation guide
One power cord
One USB interface cable
MH240 Series
MH240T Series
MH240P Series
Note: Check the production date
Serial NO.: XXX 17 22 XXXX
YEAR WEEK
Год Неделю
