TSC MH640T [13/73] Printer optional features
![TSC MH340P [13/73] Printer optional features](/views2/1244192/page13/bgd.png)
- 4 -
Others
Standard for real time clock
Standard for buzzer
Standard industry emulations right out of the box including Eltron® and Zebra® language support
Built-in Monotype True Type Font engine
Downloadable fonts from PC to printer memory
Print head pressure force & pressure location adjustable
1.2.2 Printer Optional Features
The printer offers the following optional features.
Product option feature
User
option
Dealer
option
Factory
option
Option Card (GPIO + Parallel)
○
Internal Bluetooth module in front panel
○
Wi-Fi module (Slot-in)
○
KP-200 Plus keyboard display unit
○
KU-007 Plus programmable smart keyboard
○
1.3 Printer Specifications
Printer Specifications
Model
STANDARD
ADVANCED
MH240
MH340
MH640
MH240T
MH340T
MH640T
MH240P
(w/ internal
full
rewinder)
MH340P
(w/ internal
full
rewinder)
MH640P
(w/ internal
full
rewinder)
Physical
dimensions
276 mm (W) x 502 mm (D)x 326 mm (H)
276 mm (W) x 502 mm (D) x 412
mm (H)
Weight
15.35 kg (33.84 lbs)
15.43 kg (34.02 lbs)
18.93 kg (41.73 lbs)
Power
Internal switching power supply
Input: AC 100-240V, 4-2A, 50-60Hz
Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
Note:
The max. full web black bar is limited to 5 mm only, otherwise printer may stop printing to
protect power supply.
Environmental
condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
