1450
Ridge Tool Company
1
WARNING! Read these instructions
and the accompanying safety booklet
carefully before using this equipment. If
you are uncertain about any aspect of using this
tool, contact your RIDGID distributor for more
information.
Failure to understand and follow all instructions
may result in electric shock, fi re, and/or serious
personal injury.
SAVE THESE INSTRUCTIONS!
Specifi cations
Type: .................................................................... RIDGID no. 1450
L/W/H: .................................... 28/8.5 /9.5 inches (71 x 22 x 24 cm)
Weight: .................................................................... 14 lbs. (6,4 kg)
Max. Pressure: ........................................................ 50 Bar/750 psi
Piston Vol.: ........................................................... 2.3 In
3
(37,7 cm
3
)
Outlet Hose: ................................................ 1/2” BSPP or 1/2” NPT
Reservoir Capacity: .................................... 3.6 gallons (13,6 litres)
Liquid: ................................................... Water, Oil, Ethylene Glycol
Max. Temp.: ............................................................... 120°F (50°C)
System: Variable lever-arm design with automatic non return valves
Application
The RIDGID Model 1450 Pressure Testing Pump is designed to pressure
test a wide range of fl uid systems for leaks including heating, compressed
air, oil, fi re sprinkler, and small bore pipeline systems using water, oil or a
mixture of water and ethylene glycol.
Note: the viscosity should be comparable with that of water for the pump
to operate smoothly.
General safety
1. Read and follow these instructions.
2. Know the location and functions of all controls before using pump
(fi g.1).
3. This pump was designed for specifi c applications. We strongly
recommend that it NOT be modifi ed and/or used for any application
other than for which it was intended.
4. Check for damaged parts before using the pump. DO NOT use if the
hose or any other part is damaged or broken.
5. When servicing, use only identical replacement parts.
Operating Instructions (see fi g. 1)
1. Connect outlet hose (a) to piping system.
2. Close pressure relief valve (b) and remove locking pin (c) from
handle (d).
3. Pump liquid into system to completely fi ll the system (fi g. 2).
(Use long pump handle strokes to fi ll system).
4. Continue to pump until desired pressure is reached (fi g. 3).
(Use short pump handle strokes to reach desired pressure).
CAUTION:
The unique pump system allows high pressures to be reached very easily.
Watch the pump’s pressure gauge (e) closely to avoid exceeding the required
test pressure. Pressures above the rated pressure of 50 Bar/750 psi will
cause damage to the pump’s components. The nylon tube (51117) will
normally burst fi rst to prevent damage to other pump components.
5. If system has no leaks the gauge will not show a drop in pressure
during test period (after temperature stabilisation).
6. Release pressure by opening relief valve.
Maintenance
Keep reservoir and pump system clean. The inlet hose is supplied with
a fi lter to prevent dirt from entering the pump. If fi lter becomes clogged,
remove from hose and fl ush clean with water (fi g. 4).
GB
1450
Operating Instructions
