tested

Ger many

EMC

www.yli.cn

We create security

RFID/Digital Keypad

Control Station

Model:YK-168

INTRODUCTION

TECHNICAL DATA

YK-168 is an RFID and digital keypad control station,designed for access control and home security

applications.The control station provides 3 operation mode: i) RFID Card operation,ii) Digital Code

operation, iii) RFID Card+Digital Code combinations operation.

YK-168 provides multi-User Codes or single User Code, and provides manual code entry or auto

code entry.

YK-168 can be connected with door opening buttons and door bell, it has the safety functions as the

keypad locks or alarms after 5-10 false entries and tamper alarm.

YK-168 has advanced features with the Microprocessorand EEPROM non-volatile memory for reliable

performance.

YK-168 is fully keypad programmable, all programming proceed on the keypad.

YK-168 is a device of simple operation, easy to use, reliable functions; it is an ideal device for

office, home and factory in access control and security system installations.

Dimensions: 117Lx117Wx21H(mm)

Operating Voltage: 12VDC+10%

Current Drain: Quiescent State=25mA, Active State=70Ma (2 Relays actuated,

all LED lighted)

Relay Output Contacts: N.O. and N.C. Dry Contact, Max Rating of Contact Current 3A/24VDC

Capacity of Recording: 250 ID Cards, 250 Codes or 1 Common Code

Card Reading Distance: Max Distance 10cm

Type of ID card: EM Card, 125KHZ

Operating Temperature: -20℃-60℃

Operating Humidity: 10%-90%

Weight: 0.14kg

AUDIBLE & VISIBLE INDICATIONS

Definition of

Audible and

Visible Indications

Standby mode

Successful key entry

Successful card / code entry

Successful operation

Unsuccessful card / code

entry

Unsuccessful operation

Status

Indicator STATUS

Amber LED

1 Flash in 2 Sec interval

1 Flash then light for 10Sec

(Press # to return to standby

mode)

2 Flashes

5 Flashes

Output

Indicator

PASS

Green LED

Light

Audible Indicator

Buzzer

1 Beeps

2 Beeps

5 Beeps

In locking status

(no response to card / code

entry)

1 Flash in 10 Sec interval

1 Short beep in 10

secretary interval

1 Long beep finish

locking

LED

Light for

10Sec

Key Act

Lamp

KEY ACT

In programming mode

Light Light
