1 - 6 ABOUT THIS PRINTER
HL7050_US_UG_FM5.5
General view
Figure 1-2
1
Control Panel
2
Face-down Output Tray
3
Support Flap
4
Top Cover
5
Multi-purpose Tray
6
Multi-purpose Extension Support
7
Paper Tray (Tray 1)
1
2
3
4
5
6
7
