Wacker Neuson BS 30, 6’’ 5216 [17/32] Technical data
![Wacker Neuson BS 30, 6’’ 5216 [17/32] Technical data](/views2/1025237/page17/bg11.png)
TD00086GB
15
TECHNICAL DATA
BS 30
Machine No. 0005216 ...
Length x width x height mm: 540 x 340 x 1000
Rammings shoe mm: 280x150
Operating weight (masse) kg: 30
Power transmission From drive engine via centrifugal clutch
Percussion rate/min. throttle regulated min
-1
: 830
Single stroke J/mkp: 32 (3,2)
Stroke of ramming shoe up to mm: 42
Drive motor 2-stroke petrol engine
Piston displacement cm
3
:80
Power kW: 1,1
Engine speed min
-1
: 4800
Fuel mixture ratio (gasoline-oil): 50 : 1
Fuel consumption l/h: 0,45
Tank capacity l: 2,2
The required sound specifications, called-for by the EC-Machine Regulations per Appendix 1, Paragraph
1.7.4.f, are
- sound pressure level at the operator's location L
pA
= 92 dB(A)
- sound power level L
wA
= 103 dB(A)
The sound values were determined according to ISO 3744 for the sound power level (L
wA
) and, alternately,
ISO 6081 for the sound pressure level (L
pA
) at the operator's location.
The weighted effective acceleration value, determined according to ISO 8662, Part 1, is 12 m/s
2
.
The sound and vibration measurements were carried out and obtained with the machine working on crushed
gravel at nominal engine speed.
