Hyundai H-HC4-25-UI710 [10/36] Operation of the infrared heater

10.

Electric ceiling heater

Connection to electric mains

1. The patio heater is designed to be connected to 220V~, 50Hz singlephase voltage mains with

a grounding circuit.

2. Prior to connection make sure that parameters of electric mains in the place of connection

comply with parameters, indicated on the identication plate with technical data of the unit.

3. It is necessary to follow active electrical safety precautions, connecting the convector to

electric mains.

4. An electric outlet must be properly grounded. The outlet must be designed for rated current

not less than 16A for models with maximum power up to 2000W. Electric outlet and plug

must always stay dry to prevent current leakage. Regularly check if the electric plug is tightly

connected to the outlet. It must be done in the following order: connect an electric plug into

an outlet, aer half hour operation turn o the patio heater and disconnect the plug from the

outlet, check if the plug is heated by your hand. If the plug heated over 50°C then replace the

outlet by a new one to prevent damages, incidents, re as a result of bad electric contact. A

specialist must do the job.

7. OPERATION OF THE INFRARED HEATER

1. Before switching on the heater, ensure that no moisture on the device and on the heating element.

2. Aer the rst turn the heater on may appear briey burnt smell. This is normal. If the smell

persists for a long time, immediately disconnect the heater from the electric power supply and

contact your service representative.

3. To exclude the appearance of burnt smell when using the heater in the future it is

recommended to keep it clean, preventing the accumulation of dust on it.

4. Within several minutes aer switching on the heater to the heating element may appear black

dots. This is normal and does not aect the operation of the device.

5. Not recommended for long look at heater heating element, this can cause deterioration and

damage to health.

WARNING!

Warning! Please connect the cable with an industrial plug rated

3P 230V 16A IP67 of IEC 60309-2.

WARNING!

Aer installation of the heater and before switching for the rst time, it is

necessary to wipe the radiating board with alcohol. Aer that, it is PRO-

HIBITED to touch the radiating board.

WARNING!

Slight crackles may be heard during operation at the moment of

heating or cooling, which disappear, when the heater reaches the

working mode.
