6. INSTALLATION

6.1 Safe distances required for installation

1. Expand the original packaging and carefully remove the heater

2. Remove the mounting kit

3. Collect the installation wall mount holes as shown in Fig. 2

4. Connect the hardware to the instructions shown in Fig. 3, 4, 5

5. Hang the heater on the smooth surface of the wall with the observance of the distance spec-

ied in item 6.1. Make sure that the mounting screws rmly fastened

6. If necessary, install the heater, bracket, follow the instructions shown on Fig. 6, 7, 8, 9 and

specied in item 6.3

6.2 Installation of the heater using the wall fasteners

Table 2

On Fig. 2, 3, 4, 5 shows stepwise instructions on assembly and installation of wall fasteners for

infrared heater.

NOTE:

To improve the product quality, the design and technical specications

of the infrared heater, as well as its delivery set can be modied by

the manufacturer without preliminary notication.

NOTE:

Depending on material and design of ceiling structural elements, the

heater is secured onto appropriate fasteners chosen on basis of the

strength condition. Strength of the ceiling or structural elements,

to which the heater is secured, should be sucient to endure 5-fold

weight of the heater.

№ Parts name Specification Qty

1 Screw M6x20 1

2 Bracket set Aluminum 1

3 Expansion bolt M6x60 2

4 Hanger STEEL 1

5 Bolt M8х60 1

5A Nut M8 1

5. DELIVERY SET

1. Infrared heater – 1 pcs.

2. Fasteners kit – 1 pcs.

3. Operation manual and warranty certicate – 1 pcs.

4. Package – 1 pcs.
