Hardware Installation
1-2 ProductSpecications
CPU Support for Intel
®
Core
™
X series processors in the LGA2066 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
X299 Express Chipset
Memory 8 x DDR4 DIMM sockets supporting up to 128 GB of system memory
(Note 1)
* Support for up to 512 GB of system memory when using Registered DIMMs.
4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
(Note 2)
4 channel memory architecture
(Note 1)
Dual channel memory architecture
(Note 2)
Support for DDR4 2667/2400/2133 MHz memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Registered DIMM 1Rx8/2Rx8/1Rx4/2Rx4 memory modules (operate
in non-ECC mode)
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC1220 codec
Support for Sound BlasterX 720°
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
1 x PCI Express x16 slot, running at x8 (PCIEX8)
2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
(All of the PCI Express x16 slots conform to PCI Express 3.0 standard.)
* The PCIEX4_1 slot shares bandwidth with the M2M_32G connector. The PCIEX4_1
slot becomes unavailable when a device is installed in the M2M_32G connector.
* Refer to "1-6 Setting up AMD CrossFire
™
/NVIDIA
®
SLI
™
Conguration,"forthe
installation notices for the PCI Express x16 slots.
Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and 3-Way/2-Way NVIDIA
®
SLI
™
technologies
(Note 1)
Support for AMD Quad-GPU CrossFire
™
and 3-Way
(Note 1)
/2-Way AMD CrossFire
™
technologies
(Note 1) Supported when using a 44-lane or 28-lane CPU.
(Note 2) Supported when using a 16-lane CPU.
