Hardware Installation
10) M2P_32G/M2M_32G
(Note)
/M2Q_32G (M.2 Socket 3 Connectors)
TheM.2connectorssupportM.2SATASSDsorM.2PCIeSSDsandsupportRAIDconguration.Please
note that an M.2 PCIe SSD cannot be used to create a RAID set either with an M.2 SATA SSD or a SATA
harddrive.TocreateaRAIDarraywithanM.2PCIeSSD,youmustsetupthecongurationinUEFIBIOS
mode.RefertoChapter3,"ConguringaRAIDSet,"forinstructionsonconguringaRAIDarray.
Follow the steps below to correctly install an M.2 SSD in the M.2 connector.
Step 1:
Get a screw and a standoff from the included M.2
screw kit. Locate the M.2 connector where you will
install the M.2 SSD, use a screwdriver to unfasten the
screw on the heatsink and then remove the heatsink.
(Only the M2Q_32G connector has the heatsink)
Step 3:
Press the M.2 SSD down and then secure it with
the screw. Replace the heatsink and secure it to
the original hole.
Step 4:
The installation is completed, as shown in the
picture above.
