NOTICE

SANIWALL

Pro is a wall unit with integrated

macerator specially designed for the installation of all

types of wall-hung toilet, shower and washbasin.

SANIWALL

Pro is designed for domestic use only.

Installed and maintained correctly, SANIWALL

Pro

will deliver a high level of performance, safety and

reliability.

Please pay particular attention to the following:

possible danger to personnel,

warning of

potential electrical hazar

“WARNING” A general warning that failure to

follow instructions could result in poor functioning

of the equipment.

Please contact our customer services for any

additional information.

LIST OF SUPPLIED PARTS

(fig.1 and fig.2)

DIMENSIONS (fig.3)

- Depth of frame = Between 200 and 245mm

- Thickness of casing = Between 16 and 100mm

- Height = Adjustable to between 1080 and 1280mm

- Bowl height = 400 mm min ( finished floor )

- Max. thickness of finished floor = 185 mm

- Height between floor and centre of macerator

discharge outlet = 220 mm mini

PERFORMANCE CURVE (fig.5)

COMBINATIONS OF HEIGHT AND LENGTH

OF THE DISCHARGE PIPE (fig.6)

INSTALLATION

(figs. 7.1 to 7.6)

SANIWALL

Pro

is designed to be flush-mounted.

Installation should only be attempted by qualified

persons.

The macerator must be located in the same room as

the toilet and any other sanitary installations that may

also be connected.

The equipment must be easily accessible for checking

and maintenance purposes.

SANIWALL® Pro MACERATOR :

AREA OF USE AND TECHNICAL DATA

Discharge of toilet waste

Area of use

Discharge of washbasin waste

Discharge of shower waste

Type P 30

Maximum vertical discharge 5m

Voltage 220-240 V

Frequency 50 Hz

Maximum absorbed power 400 W

Maximum absorbed current 1.8 A

Appliance class I

Protection index IP44

Net weight 5.6 KG

WARNING: This equipment should not be used for

purposes

other than those describ

ed in these

instructions.

PREPARING THE FRAME

FITTING THE TOILET BOWL ANCHOR RODS

AND FIXING TO THE WALL

1 -

WARNING: This frame should be fitted on a load

bearing wall if the floor structure is lightweight or

on a partition wall if the floor slab is suitable (NF

safety test: 400kg for wall-hung bowl). For

packaging purposes, the feet are folded inwards.

To reposition them correctly, they should be turned

outwards by a quarter turn.

2 -

Measure the centre-to-centre distance (A)

between the bowl anchoring holes: there are only

2 possible measurements: (Ka = 230 mm ) and

(Kb = 180 mm).

Insert the rods into the holes of the frame, as

per the centre-to-centre distance and fix them in

place using the nuts.

3 -

Place the frame in position.

4 -

Place the wall fixing lugs against the wall and

fix them to the frame using the nuts, after having

hecked that the frame is vertical

5 -

Using a hacksaw, cut off any excess threaded rod

from the fixing lugs.

7.1

7.1.a

ADJUSTING THE HEIGHT OF THE FRAME

1 -

Place the frame in its desired position.

2 -

Unscrew the 4 set screws .

3 -

Adjust the height of the feet so that the front of the

bowl is 400mm from the finished floor.

4 -

Check that the frame is horizontally level and

retighten the 4 set screws .

PREPARING FIXING

1 -

Mark out your drill points

(2 on the wall and 6 on the floor).

2 -

Move the frame away and, using a 10mm bit, drill

2 holes (min. depth 70mm) in the wall.

Use an 8mm bit to drill 6 holes (min. depth 65mm)

in the floor.

3 -

Insert the dowels and into the holes.

4 -

Reposition the frame and move on to connecting

the SANIWALL

Pro

macerator.

7.1.b

7.1.c

III
