TECHNICAL ADVICE FOR DISCHARGE

PIPEWORK :

• Avoid “low points” in the discharge pipework by

keeping it straight with clamps.

• Allow a 1:100 fall for “horizontal” pipe runs

• If vertical lift is required:

Any “uphill” pipework should run directly upwards

from the unit.

Maintain a gravitational discharge (1:100 fall).

• We advise fitting a drain-off point at a low

point, to facilitate maintenance work.

•

To prevent

siphonage:

- fit a vacuum relief valve (Nicoll type or

similar) at the highest point in the pipe run, or

-increase the diameter of the horizontal pipework.

• Discharge from the unit should be connected to

the soil stack using a strap on boss.

• Ensure pipework is adequately lagged to protect

against freezing.

N.B : Any elbow fitted along the discharge pipe will

create friction loss in the region of 50cm per elbow.

possible, use smooth curved elbow bends to optimise

flow.

• We recommend the installation of an

SFA Sanialarm external alarm system, which

warns the user in the event of macerator

malfunction. The drill point is shown on the lid.

FIXATION DU BROYEUR ET DU BATI

1 -

Using the half-clamp , fix the macerator onto the

frame.

2 -

Using the screws provided and ), fix the

frame in place using the dowels in the floor and

wall. The assembly must be extremely solid and

comply with NF standards.

ELECTRICAL INSTALLATION:

The electrical installation should only be

carried out once all plumbing connections

have been fitted.

The electrical installation should only be carried out by

a qualified person.

The unit must be positioned within easy reach of an

electrical point.

The unit’s power circuit should be connected to a fully

earthed electrical supply (class I) and be protected by

a highly sensitive differential circuit breaker (30mA),

et to 10A min.

The electrical supply should power the unit only. If you

have any doubts, have the installation inspected by a

qualified electrician.

Regulations

All wiring should comply with the applicable standards

in the country of use (France: NF C 15-100) regarding

protection requirements for bathrooms. If you have any

doubts, contact a qualified electrician. If the unit cable

s damaged, this should be replaced by the

manufacturer or after-sales service, in the interests of

personal safety.

INSTALLING THE MACERATOR

(fig 7.2)

PREPARING THE MACERATOR

1 -

From the accessories supplied with the macerator,

select the white seal and the cap plate .

Fit these 2 parts on the macerator’s large inlet.

2 -

From the accessories supplied with the macerator,

select the discharge elbow , the white pipe ,

the two small clamps and the 23/32 reducer.

Connect these parts together (the white pipe can

be cut according to the required discharge

distance).

3 -

Depending on the side chosen for the discharge

stack, position the assembly and insert the elbow

into the soil pipe and connect it using the

clamp .

4 -

If a washbasin is to be connected, you must first

trim off the top of the shaft using a hacksaw,

ensuring that the edges are smooth.

Pull the flexible sleeve over the shaft and fix in

place using the clamp .

5 -

If a shower is to be connected, unscrew one of

the tank plugs according to where the shower

will be. Fit a flexible sleeve on the water inlet,

fixing it in place with a clamp .

WARNING: When connecting a shower, ensure

that the base of the shower tray is raised at least

13cm from the floor. If you raise the SANIWALL

Pro

unit, please bear this in mind when calculating the

height of the shower tray.

For example, if you raise the unit by 5cm, you will

need to raise the shower tray by 13+5=18cm

(recommended discharge slope = 3%).

6 -

Once the macerator is ready (depending on the

type of installation) it can then be slid into the

frame. You are now ready to fit the pipework and

carry out the electrical installation.

If this proves difficult, you should:

- either identify the position of the macerator in

relation to the floor and wall, and remove the frame

so you can carry out a trial installation, or

- leave the frame in place and remove the central

removable frame by removing the screws , in

order to give yourself more room to work in.

Zk Zd

7.2

7.2.a

7.2.b

7.2.c

7.2.d
